T85602 Large Cam Bearing Removal and Installation Tool for GEVO and Tier 4 Engines
T85602 Large Cam Bearing Removal and Installation Tool for GEVO and Tier 4 Engines
This tool is used to install and remove the large camshaft bearings on GEVO and Tier 4 engines. For bare frames a starter spacer (ref. 1) is included to start the installation process. This kit is normally powered with a T85601B Double Acting Ram, but only one hose is attached to the single acting ram.
The T85602SB (ref. 5) is a small diameter mandrel that can be used to install large bearings by anchoring in the small diameter bore. The T85602PC (ref. 4) is a pushing collar that is used to remove the large bearings.
| 1 | T22810 | Hydraulic Ram w/Elbow |
| 2 | T85603LBI | Large Bearing Installation Mandrel |
| 3 | T85603LBR | Large Bearing Reaction Mandrel |
| 4 | T85602PC | Pushing Collar |
| 5 | T85602SB | Small Bearing Mandrel |
| 6 | T85602SS | Starter Spacer |
